This 4-panel, 800-watt kit is ideal for charging large battery banks.
The 800 watt Solar AE-4 kit is one of the latest offerings from Go Power! The multi-panel kit provides 800 watts / 38.4 amps of output power and paired with a Go Power! makes it ideal for charging power-hungry appliances in your RV, like an all-electric refrigerator. Choosing a solar panel kit for your RV or boat eliminates the need for conventional battery charging systems, such as generators. Take your next adventure off the grid. The Solar AE-4 kits comes with a 25 year limited power output warranty.
*Best paired with Power or Power.
Kit Includes:
- 800 watts / 38.4 amps solar charging kit (4x 200-watt Solar Panels)
- 2x 30-amp MPPT Solar Controller
- NEW PowerTrak™ 3” color touch-screen remote display (GP-RVC-DIS-3)
- 25′ of Solar output cable – RED (#10)
- 25′ of Solar output cable – BLACK (#10)
- Mounting hardware (4 x GP-MH-4-KB)
- 25-year solar module power output warranty
Product Specifications
SOLAR PANEL SPECS
| Solar cell type | Monocrystalline |
| Output power | 200 W |
| Rated current | 9.62 A |
| Rated DC voltage | 20.8 V |
| Open-circuit voltage | 24.3 V |
| Module efficiency | 21.5% |
| Connectivity | Solar Branch Connectors |
| Frame type | Clear anodized aluminum frame |
| Certifications | CE |
| Dimensions | 59.1 x 26.3 x 1.57 in / 1500 x 668 x 40 mm |
| Weight | 26.4 lbs / 12 kg |
| Warranty | 25 YEARS POWER OUTPUT (module) |
SOLAR CONTROLLER SPECS
| SPEC | GP-RVC-MPPT-30 | ||||
| System Voltage | 12/24V | ||||
| No-load Loss | 8ma | ||||
| Max PV Input Voltage | <100V | ||||
| Rated Current Charge | 30A | ||||
| Max PV Input Power | 600W/12V;1200W/24V | ||||
| Battery Type Selection | GEL | AGM | FLOODED | LiFePO4 | Custom |
| Equalize Charge Voltage | – | – | 14.9V/29.8V | – | 8.32V |
| Bulk-Absorption Voltage | 14.1V/28.2V | 14.4V/28.8V | 8.32V | ||
| Float Charge Voltage | 13.7V/27.4V | 14.0V/28.0V | 8.32V | ||
| Recharge Voltage | 13.2V/26.4V | 8.32V | |||
| Over-Discharge Return Voltage | 12.8V/25.2V | 12.2V/24.4V | 8.32V | ||
| Under-Voltage Warning Level | 12.0V/24.0V | 8.32V | |||
| Over-Discharge Voltage | 11.0V/22.0V | 8.32V | |||
| Operation Temperature | -35°C ~ 45°C | ||||
| Dimensions | 3.37 x 7.77 x 5.71 in (85.6 x 197.5 x 145 mm) | ||||
| Weight | 3.14lb (1.42kg) | ||||
| IP Protection | IP30 | ||||
| Communication | RS485, Canbus | ||||
| Operation Altitude | < 3000M | ||||
| Warranty | 5-years | ||||
POWERTRAK™ SCREEN
| Display Size | 3.2 inches |
| Display Resolution | 320×240 |
| Touchscreen | Resistive |
| Supply Voltage | 12-48 VDC |
| Max Supply Current | @ 12 VDC Input – 400 mA @ 24 VDC Input – 200 mA |
| Operating Temperature Range | -20 to 50 °C |
| Storage Temperature Range | -30 to 70 °C |
| Humidity | 5-95 % RH, non-condensing |
| Bluetooth Range | 50 meters |
| WiFi Bandwidth | 2.4 Ghz |
| LCD Screen | 320×240 resolution |
| Connectivity | 4 pin, 2mm pitch header connection |
